Specifications
- Riveting Capacity 3.0mm, 3.2mm, 4.0mm,4.8mm Standard blind rivets and monobolts
- Weight (without nose equip) 1.98kg
- Weight (min. with equip) 2.1kg
- Pull Force @ 5.5 bar 9.34 KN
- Stroke (min.) 17mm (0.67 in)
- Cycle time (approx.) 0.8 sec
- Air supply pressure 5-7 bar (80-100 psi)
- Free air volume @ 5.5 bar 2.1 litres
- Noise level <75 dB(A)
- Vibration <2.5m/s2
Benefits
- Reduced operator fatique
- High placement speed
- Robust tool
- Minimized air consumption
- Reduced setting times and change of equipment
- Reduced time to empty stem collector
- Places a wide range of fasteners
- Ergonomic
